Where Can I Find Jeep Wrangler Fuse Box?- (Here Is The Location)

Jeep Wrangler fuse boxes can be found in different locations based on the year and model. It could stress you out if you don’t know the exact location of the fuse box.

So, where can you find Jeep Wrangler fuse box? The fuse box can be in the back of the battery of the engine chamber. It can also be located below the small cupboard in a car. However, these locations depend upon their models.

This guide will assist you in finding the exact location of the Jeep Wrangler fuse box. Check out this article till the end to learn more!

Where Can I Find Jeep Wrangler Fuse Box?

Given that, fuse boxes can have different locations according to the year and model. Well, it is not that hard to find. Here I have addressed some of the Jeep Wranglers locations with diagrams. Check below to learn about it.

Jeep Wrangler 1995

The fuse box of this model is located below the dashboard. You won’t have to put much effort in finding it. Here is a diagram of the Jeep Wrangler 1995 fuse box-

(diagram source)

Circuit box information

Jeep wrangler 1995 circuit box has 12 fuse. The fuse color consists yellow, lt blue, red, natural, tan, gold and lty blue. All fuses are fitted in different components. Here are some of the components –

1. Rear wiper
2. Stop lamps and buzzer
3. Turn signal lamps
4. ASD and fuel pump relays
5. Heated rear window
6. Ciger lighter and accessories
7. Running lamps
8. Buzzer, gaudge and warning lights, relays and backup lamps
9. Panel illumination lamps
10. Front wiper and washers
11. Heater and A/C

Jeep Wrangler 2015

Jeep Wrangler 2015 fuse box is located below the hood. So, when you open up the hood, you can see a black box on the car engine. It is toward the front of the battery. For your better understanding, have a look at the following diagram of the Jeep Wrangler 2015 fuse box –

(diagram source)

Circuit box information

Jeep wrangler 2015 have 38 fuse. Pink, natural, green,yellow, blue and red are the color. The 10 components of it are given below-

1. Transfer case module
2. Driver door node
3. Passenger door node
4. Anti-Lock Brake System (ABS) Pump/Stability Control System
5. PZEV Sec Motor/Flex Fuel
6. Headlamp Wash Relay/Manifold Tuning Valve
7. Sway Bar
8. Rear Blower Motor/Radiator Fan
9. Ignition Off Draw (IOD)
10. Rear defroster

Jeep Wrangler 2018

The fuse box of Jeep Wrangler 2018 is located under the hood in the left side of the engine chamber. You can find it right at the back of the battery. If it is hard to find, know that you can find it using the following pattern.

1. First, you can see the air filter
2. Then you can see the battery
3. Finally, you will find the fuse box

Here is the diagram of the Jeep Wrangler 2018 fuse box –

(source diagram)

Circuit box information

Jeep Wrangler 2015 has 111 fuse. The fuse color consists Tan, yellow, blue,green, clear and red. Some of its components are –

1. Spare

2. Starter

3. Ibs

4. security gateway

5. ECM etc

6. Ciger ltr

7. Frt Drvr Htd Seat

8. LBSS/RBSS

9. IN-CAR TEMP SENSOR

10. BRAKE VAC PMP 2 — If Equipped

Signs Of A Bad Fuse Box

A bad fuse box starts to show the signs instantly after something has gone wrong with it. So if you see these signs frequently, then there is a huge possibility that your Jeep Wrangler’s fuse is faulty.

Being able to know the signs from before will lead you to take fast steps toward the solution and it will also save you from spending a lot of money. So lookout the signs below of a bad fuse box –

Cut-off devices

When the circuits of the fuse gets overloaded, those circuits cutt off the power. This problem does not only blow the fuse but also cut-off devices linked with the car

Burning smell

If you notice a burning smell coming from the fuse area, then be sure that fuses have blown up or burned. Then you have to check the fuse area and fix the problem faster.

Wobbly fuses

Fuses come loose when the terminals have been destroyed anyway. And around that time, you may face power loss of different functions too. This is the time  you should understand that fuse is bad.

Cut off power

Overloaded circuits cut-off the power of many functions. You may face trouble with interior lights, cars not starting etc.

Fuel Pump failure

Sometimes fuel pump not giving fuel can be the significant signs of a faulty fuse. If you notice this sign, you have to take action toward the solution at earliest.

How Do I Check The Fuse Box?

When you want to check the fuse box of the vehicle to know if there is any problem, you may need a proper guide to do that. Follow below steps to check the fuse box –

1. Take a screwdriver and unscrew the cap
2. Now, check the condition of the wire
3. If you can notice a gap between the wires, it means that fuse have blown out
4. If the fuse have blown out, you should replace the fuse box very soon.

How To Replace The Fuse Box?

If you have diagnosed that your Jeep Wrangler’s fuse is blown, you have to take a step finally to replace the fuse box.

Follow below steps to replace the fuse box –

1. Once you have discovered the fuse box location of the wrangler, now you have to disengage the fuse panel.
2. Now take off the cover to reach to the circuit panel.
3. Disengage the power supply
4. Remove the bolts
5. Now install the new fuse box in that location
6. Reconnect and re-install everything back to the place

Conclusion

When we want to check or replace the fuse box, we can’t do that without being aware of the location. Simply, fuse boxes of different vehicles (model and year) are located in different locations.

Now, in the above article, I have covered  1995,2015 and 2018 Jeep Wrangler fuse box locations, signs of a bad fuse box, how you can check and replace the fuse box here.

 So, check out the location of your Jeep wrangler from here. If you can’t find the location of the fuse box, because you have other model of Jeep Wrangler, then you can try finding it in other articles.
